Model
|
PTZ14-OB-4G Dual Lens
4G Speed Dome Camera
|
|
Camera
|
Operating system
|
Embedded Linux
|
|
CPU/Image sensor
|
1/2.9 inch progressive scan CMOS sensor
|
|
Minimum illumination
|
0.5 Lux(Color mode), 0.1 Lux(B&W mode)
|
|
Resolution
|
3MP+3MP
|
|
Lens/Viewing angle
|
3.6mm F2.0/101°(Diagonal)
|
|
Night vision
|
IR-CUT with auto-switching,12 pcs Infrared LED, 6 pcs IR
LED lights, Irradiation distance: 20~30 m
|
|
Compression standard
|
H.265 main profile
|
|
Data Rate
|
Main stream: 3MP
|
|
Bit rate/maximum frame rate
|
1~30fps
|
|
Image adjustment
|
Brightness and contrast are adjustable
|
|
Audio
|
Input
|
Built-in -38dB microphone
|
|
Output
|
External 3W High sound quality,Loud speaker 130 dB
|
|
Sampling frequency/bit width
|
8KHz/16bit
|
|
Compression standard/Bit Rate
|
G.711/64kbps
|
|
Network
|
Network interface
|
10Mbps/100Mbps adaptive /RJ45
|
|
Network Frequency
|
4G FDD-LTE/TD-LTE/WCDMA/HSPA+/TD-SWCDMA/GSM/GPRS/EDGE,B1/B3/B7/B20/B38/B39/B40/B41/B26
|
|
Pan & Tilt
|
Pan & Tilt
|
Pan 355° /Tilt 110°
|
|
Storage
|
Storage functions
|
Supports TF Card(Max 128G),Cloud Storage
|
|
Alarm
|
Alarm detection
|
Motion detection; Humanoid detection; Humanoid tracking; Smoke
sound detection; Absence detection; Alarm voice prompt , flash
& irradiation; LED light timing ON & OFF
|
|
Physical
Indicators
|
Rated voltage
|
DC12V
|
|
Power consumption
|
Rated power: 4.5 W (With IR LED lights ON)/ Max power:
11 W (With Pan & Tilt ON)
|
|
Operating condition
|
Temperature: -10~50℃, Humidity: <90%
|
