Tuya smart 4ch 2MP/3MP/5MP Wireless NVR Kits |
|
| SN-TZ04 |
NVR Features:
* 4CH 2MP/3MP/5MP Wireless NVR
* NVR Built-in Wifi Router, Bandwidth-friendly
* Support Video Preview/Recording/Playback/USB Backup
* Support Android/IOS/Pad/PC Remote View
* Networking Protocol: UPNP, SMTP, PPPOE, DHCP etc.
* Get Instant Email Alerts When Motion is detected
* 1 SATA Port, Up to 4TB Each, 1 USB 2.0 Port
* Power Supply: DC12V
Camera Features:
* Sensor: 1/2.8" Progressive CMOS Sensor+PIR Sensor
* Resolution: 2MP/3MP/5MP Optional
* Lens: 3.6mm
* Auto White Balance and 3D-DNR
* Night Vision: 3pcs IR LED 100Ft(30m)
* Minimum Illumination: Colour 0.1 Lux, B/W 0.01 Lux
* Weatherproof: Yes (IP66)
|
 |
|
|
|
|
|
Model
|
SN-TZ04
|
|
Package
|
|
NVR
|
1x4CH NVR
|
|
Camera
|
4PCS WIFI Camera
|
|
Mouse
|
1xUSB 2.0 Mouse
|
|
Adaptor
|
5PCS Power Adaptor,4PCS for Cameras, other one for NVR
|
|
Camera Type
|
2.0MP(1080P) WIFI Camera
|
|
Lens
|
3.6mm fixed lens
|
|
Night Vision
|
|
Infrared LED
|
3PCS IR LED
|
|
Infrared Distance
|
20M
|
|
General
|
|
Weatherproof Housing
|
IP66
|
|
IR Cut Filter
|
YES
|
|
Operation Temperature
|
-10℃ ~ +50℃ RH95% Max
|
|
Power Source
|
DC12V±10%
|
|
Video
|
|
Input
|
4Channel, IP
|
|
Output
|
1 VGA, 1 TV,1 HDMI
|
|
Audio
|
|
Input
|
4Channel, RCA
|
|
Two-way Audio
|
NO
|
|
Output
|
1 Channel, RCA
|
|
Alarm
|
|
Motion Detection
|
4Channel
|
|
Trigger Events
|
Recording, Tour, Alarm, Video Push, Email, Screen tips
|
|
Email Alarm
|
Send Pieces to The Designated E-mail
|
|
Recording
|
|
Video Compression
|
H.265
|
|
Audio Compression
|
G711A
|
|
Video Quality
|
Best/Fine/Normal
|
|
Record Mode
|
Manual\Timer\Motion Detection\Sensor
|
|
Playback & Backup
|
|
Sync Playback
|
4 Channel / 1Channel
|
|
Remote Playback
|
4Channel/ 1Channel
|
|
Search Mode
|
ALL, Channel, Manual, Time, Date, Motion Detection
|
|
Playback Functions
|
Play, Pause, Stop, Rewind, Fast play, Slow play
|
|
Backup Mode
|
USB Device/Network
|
|
Network
|
|
Interface
|
1 RJ45 10M/100M Adaptive Ethernet Interface
|
|
Network Functions
|
HTTP, IPv4,IPv6, TCP/IP, SMTP, DHCP, DNS, PPPOE, DDNS,NTP,DST
|
|
CMS Software
|
Support Windows XP /Windows Vista/Windows 7/Windows 8/Windows 10
|
|
Extra Stream
|
CIF/QCIF(1~25fps)
|
|
Smart Phone
|
iPhone, ipad, Android ,Android pad
|
|
Hard Disk Driver
|
|
Interface Type
|
1 SATA Interface
|
|
Capacity
|
Up to 4 TB Capacity
|
|
General
|
|
Working Environment
|
-10~55℃/10~90%
|
-
|
|
|
|
