SINOVISION HD 1.0MP/720P Plug & Play WIFI IP camera

SN-IPCH10-MPT04
Feature
*Captures 720p, High-Definition (HD) video and images

*Pan : 355° - Tilt : 120°

*11 LEDs along with IR cut, IR distance: 10 meters
*2-Way audio communication - built-in microphone and speaker
*Supports (up to) 64GB Micro SD Card for recording

*Remote access from iOS/Android Devices (smartphones, tablets)

*Simple Plug-n-Play installation



  • Main Feature

    *Captures 720p, High-Definition (HD) video and images
    *Pan (Horizontal Control): 355° - Tilt (Vertical Control): 120° - with 15 Presets available
    *11 LEDs along with advanced IR cut technology, captures clear images in the dark at up to 10 meters
    *2-Way audio communication - built-in microphone and speaker with 3.5mm auxiliary audio input and output
    *Supports (up to) 64GB Micro SD Card for recording (Micro SD Card sold separately)
    *Remote access from iOS/Android Devices (smartphones, tablets, etc.), from a local computer, or from any computer via the cloud
    *Simple Plug-n-Play installation - no complicated programming or port forwarding required

    Specification

    Model SN-IPCH10-MPT04
    System security Account, password authority management
    Free DDNS Free DDNS, supports dynamic IP
    View by phone Support HD pic IOS, Android mobile view (iOS 4.3,Android OS 2.3 above)
    Local Storage support up to 64GB MicroSD card ,24-hour loop recording.
    Monitor Advantage Support PC computer monitoring, smartphone multi-pic view.
    PnP

    Plug & Play,99% penetration rate, Easy to setup:

    1.connect the network cable and power adapter,

    2.install APP, scan UID code to add camera.

    3.click online camera to view the camera.

    Sever cluster Using Amazon Cloud PnP servier cluster, intelligent application and super stable
    UID Technology UID scan technology applied, easy to operate, and highly confidential.
    Super Client

    1,4,9,16,25,36, 64,81-channel central management software, no user number limitation,

    centralized surveillance, remote record and playback, alarm email etc.

    System
    OS Embedded Linux OS
    Control protocol ONVIF 2.0 protocol, high interoperability
    Video coding Multi stream:720P@30fps+VGA@30fps+QVGA@30fps+720P @1fsJPEG capture
    Bit Rate CBR/VBR, output bit rate range:128~4096kbps
    Processor Hi processor, built in ARM926 @Max. 440MHz and high-speed video co-processor
    Video
    Compression Format H.264 baseline profile@levels:3.1/Motion-JPEG
    Frame rate 30fps/24fps(720p)
    Resolution 720P(1280*720), VGA(640*480), QVGA(320*240)
    Picture Adjustment Contrast, Brightness, Saturation are adjustable.
    Sensor 1/4 720p Progressive CMOS sensor
    Minimum illumination 0.8Lux/F1.4(colourful model ),0.3Lux/F1.(B&W mode)
    SNR ≥39dB
    IR control


    IR turned on: night vision view enabled, infrared Ray, ICR auto detect.

    IR turned off: night vision disabled, infrared ray off, ICR stay in day view mode.

    Electronic shutter 1/50s(1/60s)-1/100, 000s
    CMOS support AWB, AGC, BLC
    Lens/viewing angle 3.6mm @F1.4/56.14°
    Night vision
    Night vision Dual IR-CUT Filter auto switch, 11pcs 850nmΦ5mm LED,10m IR distance
    Audio
    Compression format ADPCM/32kbps
    Input 1 Channel Line in (3.5mm phone jack) &1 Channel Internal -48dB Microphone
    Output 1 Channel Line out (3.5mm phone jack)&Internal speaker(8Ω1W)
    P/T
    P/T Pan:355°,Tilt:120°
    Preset Postion suppor up to 15 preset postions
    Network
    network interface 10Base-T/100Base-TX Ethernet interface
    Network Protocol TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,P2P,etc
    wireless network security WPS encryption
    Online visitor Support 4 online visitors simutaneoursly
    IP address Dynamic IP and static IP address
    WIFI WIFI 802.11 b/g/n
    Others
    housing material engineering plastics
    Application environment Indoor
    Rated Voltage DC5±0.3V
    Temperature ·-10~50 °C
    Power consumption rated power:3.5W(IR opening )/maximum power:7W(P/T working )
    Package size 195x140x130mm (L×W×H)
    Weight Gross Weight :755g(Note: in kind prevail)
    Accessories Power adapter, user manual, warranty card, mounting bracket, screws.
    Motion Detection Support motion detecting
    System Requirement
    System configuration Win98 SE/ME/2000/XP,Vista,iPhone iOS4.3,The android version 2.3 or higher
